Design of an Electro-Optic Modulator for Radio-Over-Fiber System using Four-Plate Electrodes Structure

Article Sidebar

PDF
Published: Mar 30, 2018
Keywords:
Electro-optic modulator, four plates structure

Main Article Content

S. Phaiboon
Department of Electrical Engineering, Faculty of Engineering, Mahidol University, Nakornpratom, Thailand.

Abstract

This paper proposes an electrooptic modulator for radio-over-fiber systems using four-plate electrodes structure. The radio-to-optic direct conversation (ROC) can convert a radio signal in to an optical signal with the same signal format. The modulator use an electo-optic crystal such as a LiNbO3 crystal with three plate on top and on plate on bottom as electrodes, which are applied the electric fields in x and z-axes to form guiding path in the crystal. With the specified dimensions, the electrooptic conversation factors of 8 deg/V and of 0.96 deg/V are obtained for z-axis and x-axis modulations, respectively.


Keywords:  Electro-optic modulator, four plates structure


Corresponding author: E-mail: [email protected]




Article Details

Issue
Vol. 1 No. 1 (2001)
Section
Original Research Articles

Copyright Transfer Statement

 The copyright of this article is transferred to Current Applied Science and Technology journal with effect if and when the article is accepted for publication. The copyright transfer covers the exclusive right to reproduce and distribute the article, including reprints, translations, photographic reproductions, electronic form (offline, online) or any other reproductions of similar nature.

 The author warrants that this contribution is original and that he/she has full power to make this grant. The author signs for and accepts responsibility for releasing this material on behalf of any and all co-authors.

Here is the link for download: Copyright transfer form.pdf





References

[1] S. Komaki, K. Tsukamoto, and M. Okada, “Multiband operation of multimedia mobile radio in the virtual radio free space network,” Proc. 2nd International Workshop on MoMuS-2. Vol.1, no.1, pp.1-4, April 1995.
[2] W.I. Way, “Optical fiber-based microcellular systems: An overview,” IEICE Trans. Commun., Vol.E76-B, no.9, pp.1091-1102, Sept. 1993.
[3] P. Suwonpahich, K. Tsukamoto and S. Komaki “Proposal of Radio-over-fiber Systems Using Cascaded Radio-to-Optic Direction Conversation Scheme” IEICE J. Trans. Cummun., Vol. E83-B, No 8, August, 2000, pp 1766-1774.
[4] Scott McMeekin, Richard M. De La Rue, and W. Johnstone, The Transverse Electrooptic Modulator (TEOM): Fabrication, Properties, and Applications in the Assessment of Waveguide Electrooptic Characteristics, IEEE J. Lightwave Technol., Vol. 10, No. 2, pp.163-168, Feb 1992.
[5] C. Sakhornsaeng, S. Somkuarnpanit and S. Khoonthaweetop “The LiNbO3 Electrooptic Modulator with Four-plate Electrode Structure” ISCIT 2001. International Symposium, Chiang Mai, Thailand 14-16 November 2001.
[6] Fahg-Shang Chen, Modulators for Optical Communications, Proceeding of the IEEE. Vol. 58, No. 10, pp. 1440-1457, Oct. 1970.
[7] Ammon Yariv, Optical Electronics in Modern Communications, New York: Oxford University Press, Inc., 1997.
[8] Ajoy Ghatak and K. Thyagarajan, Optical Electronics, Great Britain: University of Cambridge, 1989.
[9] Shun Lien Chuang, Physics of Optoelectronic Devices, John Wiley & Sons. Inc., 1995.
[10] J.F. Nye, Physical Properties of Crystals, Great Britain: Oxford University Press, 1979.
